1080AE-01

Series: Model 1080 Stainless Steel Thermocouple Head Brand: International Metal Engineering (IME)

IME Model 1080 Connection Head, Explosion-Proof, Aluminum, 1/2" NPT, FM/CSA, Teflon Grey Coated

Price
$174.44 USD
Stock
Out of Stock
Request Information
Description
  • Conduit Connection: 3/4" NPT
  • Instrument Connection: 1/2" NPT
  • Housing Material: Aluminum
  • Environmental Rating: NEMA 4, IP66
  • FM/CSA Explosion Proof
    • Class I, Division I; Groups B,C,D
    • Class II, III, Division I; Groups E,F,G
  • Conduit Connection: 3/4" NPT
  • Instrument Connection: 1/2" NPT
  • Housing Material: Aluminum
  • Environmental Rating: NEMA 4, IP66
  • FM/CSA Explosion Proof
    • Class I, Division I; Groups B,C,D
    • Class II, III, Division I; Groups E,F,G
Close

Specifications

Brand

Approvals & Certifications

  • CSA - Class I, Div I Groups B, C, D, Class II, Div I Groups E, F, G. NEMA 4X.
  • Ex - ATEX II 2 GD. Ex d IIC Gb Ta = -40° to 85° C. Ex Tb IIIC Db IP68
  • FM - Class I, Div I Groups B, C, D, Class II, Div I Groups E, F, G. NEMA 4X, IP66.
  • IECEx - Ex d IIC Gb Ta = -40° to 85° C. Ex Tb IIIC Db IP68.

BSP Connection

  • 1/2” BSP Female

Enclosure Finish

  • Electro-Polished

Enclosure, Body Material

  • 316 Stainless Steel

Environmental Protection

  • IP66
  • IP68
  • NEMA 4X

Metric Connection

  • M20 x 1.5 Female

NPT Connection

  • 1/2” NPT Female
  • 3/4” NPT Female

O-Ring Material

  • Buna-N
